Available models
CENA710DI/W | White version – 16Ω (RAL9016) |
CENA706I/W | White version – 100V (RAL9016) |
CENA706/B | Black version – 100V |
CENA710D/W | White version – 16Ω |
System specifications
Peak power handling | 40 W | |
Program power handling | 20 W | |
RMS/AES power handling | 10 W | |
Sensitivity (1W/1m) | 96 dB | |
Speaker type | Broadband | |
Impedance | 8 Ω (CENA706) | |
Connection | SnapConnect™ | |
Screw terminal | ||
Impedance | 16 Ω (CENA710D) | |
Drivers | 6.5” Full Range | |
Sound Pressure (Max. W/1m) | @ 100 V | 106 dB |
Frequency | Response (± 3 dB) | 100 Hz – 15 kHz |
Range (-10 dB) | 70 Hz – 18 kHz | |
Line Transformer Tappings | 1 | 6 W / 1667 Ω |
2 | 3 W / 3333 Ω | |
Dispersion | Conical | 140° |
Product Features
Cut-out measurement | 167 mm (Ø) |
Dimensions | 193 x 70 mm (Ø x D) |
Construction | ABS |
Front finish | borderless finely perforated steel grill |
Built-in depth | 67 mm |
Mounting | SpringFit™ mounting system |
Colours | White (RAL9003) (CENA706/W) |
Black (RAL9005) (CENA706/B) | |
Weight | 0.71 kg |
Operating temperature | -15 °C ~ 55 °C |
Recommended applications
Corporate
|
Retail
|
Bars & Restaurants
|
