Available models
| CENA506/W | White version – 100V |
| CENA506/B | Black version – 100V |
| CENA510D/W | White version – 16Ω |
| CENA506I/W | White version – 100V (RAL9016) |
| CENA510DI/W | White version – 16Ω (RAL9016) |
System specifications
| Peak power handling | 40 W | |
| Program power handling | 20 W | |
| RMS/AES power handling | 10 W | |
| Sound Pressure (Max. W/1m) | @ 100 V | 103 dB |
| Sensitivity (1W/1m) | 93 dB | |
| Speaker type | Broadband | |
| Connection | SnapConnect™ | |
| Impedance | 8 Ω (CENA506) | |
| 16 Ω (CENA510D) | ||
| Frequency | Response (± 3 dB) | 100 Hz – 15 kHz |
| Range (-10 dB) | 80 Hz – 18 kHz | |
| Line Transformer Tappings | 1 | 6 W / 1667 Ω |
| 2 | 3 W / 3333 Ω | |
| Dispersion | Conical | 155° |
| Connection | Screw terminal | |
| Drivers | 5” Full Range | |
Product Features
| Cut-out measurement | 150 mm (Ø) |
| Dimensions | 180 x 60 mm (Ø x D) |
| Construction | ABS |
| Front finish | borderless finely perforated steel grill |
| Built-in depth | 57 mm |
| Mounting | SpringFit™ mounting system |
| Colours | White (RAL9003) (CENA506/W) |
| Black (RAL9005) (CENA506/B) | |
| Operating temperature | -15 °C ~ 55 °C |
| Weight | 0.66 kg |
Recommended applications
|
Corporate
|
|
Retail
|
|
Bars & Restaurants
|
