Available models
MERO2I/W | White version – 8Ω (RAL9016 + Logo) |
MERO2 | White version – 8Ω |
MERO2D | White version – 16Ω |
System specifications
Speaker type | Full range | |
Peak power handling | 40 W | |
Program power handling | 20 W | |
RMS/AES power handling | 10 W | |
Impedance | 8 Ω (MERO2) | |
16 Ω (MERO2D) | ||
Sensitivity (1W/1m) | 83 dB | |
Sound Pressure (Max. W/1m) | 93 dB | |
Frequency | Response (± 3 dB) | 120 Hz – 20 kHz |
Range (-10 dB) | 100 Hz – 20 kHz | |
Dispersion | Horizontal | 165° |
Vertical | 165° | |
Connectors | Gold-Con™ spring clamps | |
Drivers | 2” Aluminium membrane |
Product Features
Dimensions | 146 x 98 x 70 mm (W x H x D) | |
Weight | 0.355 kg | |
Construction | ABS | |
Front finish | Thin edged white grill (RAL9003) | |
Cut-out measurement | 128 x 80 mm | |
Built-in depth | 70 mm | |
Mounting & handling | 2 Screw quick-fixing mechanism | |
Operating temperature | -20 °C ~ 60 °C | |
Colours | Black frame & white grill | |
Accessories | Included | Cut-out template |
Optional | WTR06 – 6W 100V line transformer | |
GLM02/B – Black grill (RAL9005) | ||
GLM02/P – Paintable grill | ||
WMM20 – In-wall box for MERO2 | ||
Included | GLM02/W – White grill (RAL9003) |
Recommended applications
Hotels
|
Corporate
|
Residential
|
Bars & Restaurants
|
Retail
|
