System specifications
| RMS/AES power handling | 4 x 120 W | |
| Frequency | Response (± 3 dB) | 50 Hz – 22 kHz |
| Signal / Noise | > 100 dB | |
| THD+N (@ 1 kHz) | < 0.3% (1/2 Rated Power) | |
| Crosstalk (@ 1 kHz) | < 80 dB | |
| Technology | Class-D | |
| Power | Supply | Switching mode |
| Source | 100 ~ 240 V AC / 50 ~ 60 Hz | |
| Inputs | Sensitivity | -0.5 dB ~ 10.5 dB |
| Impedance | 10 kΩ balanced | |
| Connector | XLR female with Male Linkthrough | |
| Outputs | Voltage / Impedance | 100 V / 83 Ω |
| 70 V / 42 Ω | ||
| 4 Ω | ||
| Connector | 4-pin Euro Terminal Block (Pitch – 5.08 mm) | |
| Common mode rejection ratio | 70 dB | |
| Protection | DC Short circuit | |
| Over heating | ||
| Over load | ||
| Signal limiting | ||
| Cooling | Temperature controlled fan | |
| Operating temperature | 0° ~ 40° @ 95% Humidity | |
Product Features
| Dimensions | 482 x 88 x 420 mm (W x H x D) | |
| Weight | 14.800 kg | |
| Mounting | 19” | |
| Unit height | 2 HE | |
| Construction | Steel | |
| Colours | Black | |
| Accessories | Included | 4 x 4-pin Euro Terminal Block outputs connector |
| Optional | CPE100 Rack mount handles | |
Recommended applications
|
Bars & Restaurants
|
|
Education
|
|
Corporate
|
|
Clubs
|
|
Retail
|
