XMP44
SourceCon™ professional modular audio system
- Remote control web interface (HTML5)
- RS232 & TCP/IP control port
- Front PFL speaker with vol. control
- 2.8″ LCD display with intuitive user interface
- Fully flexible modular structure
- 4 x SourceCon™ interface card slots
- Wide variation of modules separately available
- Front USB interface for each module (4x)
- Simutaneous operation for all modules
Description
System specifications
| Inputs | Type | 4 x SourceCon™ interface card slots |
| 4 x USB interface | ||
| Control | Front panel | |
| RS-232 | ||
| TCP/IP | ||
| Audac Touch™ | ||
| Web (HTML5) | ||
| Frequency | Response (± 3 dB) | 20 Hz – 20 kHz |
| Display | Type | 2.8” Graphical LCD |
| Monitoring | Front PFL speaker with vol control | |
| Power | Source | 110 ~ 240 V AC / 50 ~ 60 Hz |
| Consumption | 2 W (without module installed) | |
| Supply | Switching mode | |
| Operating temperature | 0° ~ 40° @ 95% Humidity | |
| Socket Connections (AUDAC Touch™) | 4 sockets | |
Product Features
| Dimensions | 482 x 44 x 330 mm (W x H x D) |
| Weight | 3.400 kg |
| Mounting | 19” |
| Unit height | 1 HE |
| Construction | Steel |
| Colours | Black |
Recommended applications
|
Bars & Restaurants
|
|
Corporate
|
|
Education
|
|
Houses of worship
|
|
Clubs
|
|
Retail
|
