COM24
Public address amplifier 240W 100V
- 2 unbalanced stereo line inputs
- 6 x Microphone input
- Priority audio inputs with phantom power
- Terminal block output connections
- Amplifier link in-& outputs
- Remote inputs, chime & mute contacts
- 5-zone output selector
- Low impedance & constant voltage output
- Table top or 19″ rack installation
Description
Available models
| COM24MK2-UK | UK plug |
| COM24MK2 | MK2 version |
System specifications
| RMS/AES power handling | 240 W | ||
| Frequency | Response (± 3 dB) | 20 Hz – 20 kHz | |
| Signal / Noise | > 90 dB | ||
| THD+N (@ 1 kHz) | < 0.5% | ||
| Crosstalk (@ 1 kHz) | > 70 dB | ||
| Technology | Class-D | ||
| Power | Supply | Transformer | |
| Source | 230 ~ 240 V AC / 50 ~ 60 Hz | ||
| Common mode rejection ratio | 70 dB | ||
| Inputs | Balanced Microphone 1 – 4 | Type | 4 x Balanced Mic./Line (-6 dB / -50 dB) |
| Connector | 2 x XLR/Jack Combo & 2 x XLR | ||
| Other | 4 x 15 V DC Phantom & 2 x Priority | ||
| Balanced Microphone 5 | Type | 1 x Balanced Mic./Line (-6 dB / -50 dB) | |
| Connector | 6.3 mm Jack | ||
| Unbalanced Stereo | Type | 1 x Stereo Unbalanced Line (+14 dB / -30 dB) | |
| Connector | RCA | ||
| Other | Remote mic (Priority mic + chime) | ||
| Tele-paging (Priority line) | |||
| Priority mute contact | |||
| Outputs | Connector | 2-pin Euro Terminal Block (Pitch – 5.08 mm) | |
| 10-pin Euro Terminal Block (Pitch – 5.08 mm) | |||
| Voltage / Impedance | 100 V / 4 Ω | ||
| Protection | DC Short circuit | ||
| Over heating | |||
| Over load | |||
| Signal limiting | |||
| Cooling | Convection cooled | ||
| Operating temperature | 0° ~ 40° @ 95% Humidity | ||
Product Features
| Dimensions | 420 x 88 x 320 mm (W x H x D) | |
| Weight | 11 kg | |
| Mounting | 19” / 2 HE or tabletop | |
| Construction | Steel | |
| Colours | Black | |
| Accessories | Included | 19” Rackmount adapter |
