| Performance | |
| Frequency Range (-10 dB) | 32 Hz – 125 Hz |
| Maximum Peak SPL at 1 m | 140 dB |
| Electronics and Connectors | |
| Nominal Amplifier Power (continuous) | 1800 W |
| Nominal Amplifier Power (peak) | 3600 W |
| Input Type | Balanced |
| Input Impeadance | 20 kohms |
| Input Sensitivity | 6.2 V (+18 dBu) |
| Audio Signal Input Connector | 2 x Female XLR |
| Audio Signal Loop Thru Connector | 2 x Male XLR |
| AC Output Connector | powerCON NAC3FCB |
| Current Draw 230 V / 115 V | 3.0 A/6.0 A |
| Certification Number | NRTL US&CA SGSNA/19/SUW/00110 |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Rectangular |
| Rigging | M10 Rigging Points |
| Finish | ISO-flex Paint |
| Color | Black |
| Dimensions ( H x W x D ) | 550 x 1.065 x 675 mm 21,7 x 41,9 x 26,6 in |
| Net Weight | 68,5 kg ( 151,0 lb ) |
| Components | |
| LF Driver | 18LX |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 1.180 x 730 x 610 mm 46,5 x 28,7 x 24,0 in |
| Shipping Weight | 73,5 kg ( 162,0 lb ) |
