Type | Portable Active DSP-controlled Loudspeaker |
Frequency Response(-10dB) | 50Hz-20kHz |
Horizontal Coverage | 80° |
Vertical Coverage | 50° |
Maximum Calculated SPL/1M (Continuous/Peak) | 125dB/131dB |
HF Driver | Customized driver, 1.4” voice coil and 1.0”exit |
LF Driver | Customized 12” driver, 2.5” voice coil |
DSP | |
Processor | 48kHz signal sampling frequency |
Presets | / |
AMPLIFIER | |
Amplifier Circuitry | Class D |
Power (RMS standards) | 800W |
Peak Power | 1600W |
Frequency Response(1W 8Ω 2ch) | 20Hz-20kHz(±0.5dB) |
Intermodulation Distortion | <0.05% |
Total Harmonic Distortion | <0.05% |
Cooling System | Cooling with fans, air convection |
Protection | DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection |
Signal Input | 2×female XLR(Mono jack 6.35)、1×wireless bluetooth、1×Mini jack 3.5 |
Signal Output | Male XLR |
Power Input | IEC power connector |
Working Voltage | 100-240V~ (±10%,50/60Hz) |
Power consumption (1/8 output power) | 55W |
CABINET | |
Cabinet Material | New polypropylene composite material |
Cabinet Color | Black is the default color |
Grille | Iron mesh |
Handles | 2 side,1 top |
Monitor Angle | Symmetrical 45° monitor angle |
Hanging Hardwares | M8 screw |
Pole Mount | Base hole Φ35mm |
Speaker Dimension (W×H×D) | 345×610×352mm |
Carton Dimension (W×H×D) | 405x680x405mm |
Net Weight | 14.0kg |
Shipping Weight | 17.5kg |
MA12
Active DSP-controlled full range loudspeaker
MA12 full range DSP-controlled speaker, is molded and made from new polypropylene composite material, with fashionable design and supreme performance.
