OVI-12
OVI-12
Features
Unique and versatile loudspeaker system
Wide variety of indoors and outdoors applications
Rich music reproduction
12” coaxial speaker with 1” compression driver
Lightweight polypropylene enclosure
Applications
Professional Installation Systems
Houses of Worship
Auditoriums/Theaters
Hotel Ballrooms and Meeting Rooms
| Performance | |
| Frequency Range (-10 dB) | 63 Hz – 20 kHz |
| Horizontal Coverage (-6 dB) | 90º |
| Vertical Coverage | 90º |
| Nominal Impedance | 8 ohms |
| RMS Power Handling | 300 W |
| Peak Power Handling | 1200 W |
| On-axis Sensitivity 1W/1 m | 96 dB SPL |
| Maximum Peak SPL at 1 m | 130 dB |
| Recommended Amplifier | INTEGRAL-A1002 INTEGRAL-A1004 |
| Connectors | |
| Audio Input Connector | Spring Terminals |
| Audio Output Connector | Spring Terminals |
| Enclosure | |
| Enclosure Construction | Polypropylene |
| Enclosure Geometry | Round |
| Color | Black |
| Depth | 290 mm (11,4 in) |
| Dimensions ( H x W x D ) | 500 x 505 x 290 mm 19,7 x 19,9 x 11,4 in |
| Net Weight | 10,5 kg ( 23,2 lb ) |
| Components | |
| LF Driver | 12MX |
| HF Driver | M-34 |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 339 x 563 x 563 mm 13,4 x 22,2 x 22,2 in |
| Shipping Weight | 12,5 kg ( 27,6 lb ) |
