DW5066
Digital all-in-one wall panel
- unbalanced stereo line input
- 2.5″ LCD display with intuitive user interface
- Terminal block connection
Description
Available models
| DW5066/W | White version |
System specifications
| Control | RS-485 | ||
| Digital audio | S/PDIF | ||
| Inputs | Unbalanced Stereo | Type | 1 x Stereo Unbalanced Line |
| Connector | RCA | ||
| Balanced Microphone | Type | 1 x Balanced Microphone | |
| Connector | XLR female | ||
| Phantom Power | 15 V DC (software enabling) | ||
| Cabling | UTP CAT 6 (Up to 300 meter) | ||
| Display | Type | 2.5” Graphical Full colour | |
| Connectors | 8-pin Euro Terminal Block | ||
Product Features
| Dimensions | 153 x 94 x 45 mm (W x H x D) | |
| Built-in depth | 37 mm | |
| Weight | 0.210 kg | |
| Construction | ABS | |
| Colours | Black (RAL9005) (DW5066/B) | |
| White (RAL9010) (DW5066/W) | ||
| Accessories | Optional | WB50/FG – Flush mount box for hollow wall |
| WB50/FS – Flush mount box for solid wall | ||
| Repeater (>300 m) | CP43ARP: bTicino version (/B & /W) | |
| CP45ARP: 45x45mm version (/B & /W) | ||
Recommended applications
|
Bars & Restaurants
|
|
Retail
|
|
Hotels
|
|
Corporate
|
|
Residential
|
