| Performance | |
| Frequency Range (-10 dB) | 40 Hz – 20 kHz |
| Horizontal Coverage (-6 dB) | 90º |
| Vertical Coverage | 50º |
| Maximum Peak SPL at 1 m | 138 dB |
| Electronics and Connectors | |
| Nominal Amplifier Power (continuous) | 1125 W |
| Nominal Amplifier Power (peak) | 2250 W |
| Input Type | Balanced |
| Input Impeadance | 20 kohms |
| Input Sensitivity | 3 V (+12 dBu) |
| Audio Signal Input Connector | 2 x Female XLR |
| AUX Input | 1 x 3.5 mm Mini Jack |
| Audio Signal Loop Thru Connector | 1 x Male XLR |
| Current Draw 230 V / 115 V | 1.5 A/3.0 A |
| Enclosure | |
| Enclosure Construction | Birch Plywood |
| Enclosure Geometry | Trapezoidal |
| Rigging | M10 Rigging Points |
| Finish | ISO-flex Paint |
| Color | Black |
| Dimensions ( H x W x D ) | 1.090 x 445 x 505 mm 42,9 x 17,5 x 19,9 in |
| Net Weight | 43,5 kg ( 95,9 lb ) |
| Components | |
| LF Driver | 15FV4 |
| HF Driver | M-28 |
| Horn/Waveguide | BC-95 |
| Shipping | |
| Carton Dimensions ( H x W x D ) | 1.195 x 536 x 581 mm 47,1 x 21,1 x 22,9 in |
| Shipping Weight | 47,5 kg ( 104,7 lb ) |
